BC2-EM08-UN8X | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Capacitive Sensor
BC2-EM08-UN8X
Order ID no. 100021822
home
Home
Loading...
Technical Data
Protection class
IP67
Switching element function
NO/NC (NO pre-set)
Output function
NPN
Cable length
2
Design
Threaded barrel
Medium
liquids, Bulk goods
Detection type
medium contact
Electrical connection
Cable
Housing material
Stainless steel
Media temperature min.
-25
Media temperature max.
70
Ambient temperature min.
-25
Ambient temperature max.
70
Measuring principle
Capacitive
Mounting conditions
Flush
Operating voltage
DC
Rated switching distance
2
Construction size
M8 x 1
Key Features
Electrical connection
Cable
Mounting conditions
Flush
Output function
NPN
Rated switching distance
2
In Stock
Price Group
E1
List Price
€177.00
Item Total
€177.00
Quantity
−
+
add_shopping_cart
Add to Cart
