PK10V-P14-2UP8X-V1141 | TURCK - Your Global Automation Partner
Pressure Sensor
PK10V-P14-2UP8X-V1141
Order ID no. 100042130
home
Home
Loading...
Technical Data
Protection class
IP65
Switching element function
NO/NC
Output function
PNP
Design
With display
Process connection
1/8″ NPT male thread, 1/4” NPT male thread
Electrical connection
Connector
Connector type
M8 × 1
Housing material
Plastic
Housing quality
ABS
Media temperature min.
0
Media temperature max.
60
Ambient temperature min.
-10
Ambient temperature max.
60
Operating voltage
DC
Electrical output
2 × switching output
Pressure type
Relative pressure
Material pressure transducer
Silicon
Pressure range
-1…10 bar
Key Features
Electrical output
2 × switching output
Process connection
1/8″ NPT male thread, 1/4” NPT male thread
Pressure range
-1…10 bar
In Stock
Price Group
G1
List Price
€272.00
