Isolating transducer

IM33-12EX-HI

Rendelési azonosító sz. 7506444

Number of channels: 1
Ex version: yes
Power supply: widerange
Protection class: IP20
Electrical connection: 4 × 5-pin removable terminal blocks with test socket, reverse polarity protected, screw terminal
Housing material: Plastic
Housing quality: Polycarbonate/ABS
Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 70
Approvals: ATEX, IECEx, cFMus, TR CU, INMETRO, Metrological Approval Russia
Signal type: Analog input (HART transparent)
Nominal voltage: Wide voltage range
Approvals: ATEX, IECEx, cFMus, TR CU, INMETRO
