Isolating transducer

IM33-22-HI/24VDC

Rendelési azonosító sz. 7506564

Protection class: IP20
Approvals: TR CU, Metrological Approval Russia
Electrical connection: 4 × 3-pin removable terminal blocks with test socket, reverse polarity protected, screw terminal
Housing material: Plastic
Housing quality: Polycarbonate/ABS
Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 70
Power supply: 24 VDC
Number of channels: 2
Ex version: no
Signal type: Analog input (HART transparent)
Nominal voltage: 24 VDC
Approvals: TR CU
