Temperature measuring amplifier

IM34-11EX-CI/K60

Rendelési azonosító sz. 7506636

Protection class: IP20
Approvals: ATEX, IECEx, cFMus, UL, TR CU, INMETRO, CCOE, Metrological Approval Russia
Electrical connection: 4 × 3-pin removable terminal blocks, reverse polarity protected, screw terminal
Housing material: Plastic
Housing quality: Polycarbonate/ABS
Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 70
Power supply: widerange
Number of channels: 1
Ex version: yes
Signal type: Temperature input
Nominal voltage: Wide voltage range
Approvals: ATEX, IECEx, UL, cFMus, TR CU, INMETRO, CCOE
