Potentiometer Amplifier

IM36-22EX-U

Rendelési azonosító sz. 7509530

Protection class: IP20
Approvals: ATEX, IECEx, TR CU, Metrological Approval Russia
Electrical connection: 4 × 5-pin removable terminal blocks, reverse polarity protected, screw terminal
Housing material: Plastic
Housing quality: Polycarbonate/ABS
Ambient temperature min.: -25
Ambient temperature max.: 70
Power supply: widerange
Number of channels: 2
Ex version: yes
Signal type: Resistance input
Nominal voltage: Wide voltage range
Approvals: ATEX, IECEx, TR CU
