Capacitive Sensor
BC10-S30-VN4X-H1141
Rendelési azonosító sz. 2506010| Raktáron | |
| Árcsoport | E1 |
| Listaár | 181,00 EUR |
Tétel összesen181,00 EUR
Mennyiség
- Design
- Threaded barrel
- Protection class
- IP67
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Plastic
- Housing quality
- PA12-GF30, PEI
- Ambient temperature min. (°C)
- -25
- Ambient temperature max. (°C)
- 70
- Approvals
- UL
- Output function
- NPN
- Measuring principle
- Capacitive
- Switching element function
- Complementary contact
- Mounting conditions
- Flush
- Operating voltage
- DC
- Construction size
- M30 x 1.5
- Rated switching distance (mm)
- 15
Főbb jellemzők
- Electrical connection
- Connector
- Mounting conditions
- Flush
- Output function
- NPN
- Rated switching distance (mm)
- 15
