- Protection class
- IP66, IP67, IP69K
- Switching element function
- NO/NC programmable
- Output function
- PNP/NPN
- Approvals
- CE, cULus
- Design
- With display (integrated probe)
- Process connection
- G 1/4'' male thread
- Immersion depth L (mm)
- 16.9
- Medium
- liquids
- Communication protocol
- IO-Link
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/Grilamid TR90 UV/Elastollan C 65 A 15 HPM 000/Ultramid A3X2G5
- Media temperature min. (°C)
- -25
- Media temperature max. (°C)
- 85
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 80
- Mounting conditions
- Immersion sensor
- Electrical output
- 2 × switching output, IO-Link
