- Protection class
- IP66, IP67, IP69K
- Switching element function
- NO/NC
- Output function
- PNP/NPN
- Approvals
- cULus
- Design
- With display (integrated probe)
- Process connection
- G 1/4'' male thread (BSP)
- Communication protocol
- IO-Link
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/Grilamid TR90 UV/Elastollan C 65 A 15 HPM 000/Ultramid A3X2G5
- Media temperature min. (°C)
- -30
- Media temperature max. (°C)
- 80
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 80
- Electrical output
- Switching output, Current output (3-wire), Voltage output (3-wire), IO-Link
- Pressure type
- Differential Pressure
- Pressure range
- 0…10 bar
