Pressure Transmitter

PT10R-2004-I2-TC11

Rendelési azonosító sz. 6837709

Raktáron
Listaár	144,00 EUR

Design: Without display
Process connection: G1/4″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Electrical output: Current output (2-wire)
Protection class: IP67
Electrical connection: Cable gland
Connector type: PG 9
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Ambient temperature min. (°C): -30
Ambient temperature max. (°C): 85
Approvals: cULus
Output function: Analog output current
Media temperature min. (°C): -40
Media temperature max. (°C): 135
Pressure type: Relative pressure
Material pressure transducer: Stainless steel 1.4016 (AISI 430)
Operating voltage: DC
Pressure range: 0…10 bar

Electrical output: Current output (2-wire)
Process connection: G1/4″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Pressure range: 0…10 bar
