TP-206A-CF-H1141-L100 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Temperature Detection
TP-206A-CF-H1141-L100
Order ID no. 9910475
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101543919
Detection type
medium contact
Electrical output
Resistance
Gross weight
28
Height
20
Length
130
Net weight
28
Dimension unit
MMT
Weight unit
GRM
Volume
52
Volume unit
CMQ
Width
20
Ambient temperature max. (°C)
120
Ambient temperature min. (°C)
-40
Approvals
cULus
Electrical connection
Connector
Connector type
M12 x 1
Design
Temperature probe
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Immersion depth L (mm)
100
Process connection
For compression fittings, thermowell or direct mounting
Mounting conditions
Immersion sensor
Measuring range
-50...500 °C
Protection class
IP67
Key Features
Electrical output
Resistance
Process connection
For compression fittings, thermowell or direct mounting
In Stock
Price Group
D2
List Price
€66.00
