Temperature Detection
TTM150C-206A-CF-LI6-H1140-L130-50/150°C
Order ID no. 9910577
In Stock
Price Group
D2
List Price
€122.00
Item Total
€122.00
Quantity
−
+
add_shopping_cart
Add to Cart
home
Turck-Shop
Sensors
Temperature Sensors
TTM150C-206A-CF-LI6-H1140-L130-50/150°C
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101383775
Detection type
medium contact
Gross weight
1.1
Height
0
Length
0
Net weight
1
Dimension unit
MMT
Weight unit
GRM
Volume
0
Width
0
Ambient temperature max. (°C)
80
Ambient temperature min. (°C)
-40
Electrical connection
Connector
Connector type
M12 x 1
Design
Without display (integrated probe)
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)
Immersion depth L (mm)
130
Process connection
For compression fittings, thermowell or direct mounting
Mounting conditions
Immersion sensor
Measuring range
-50...150 °C
Operating voltage
DC
Protection class
IP67
Key Features
Process connection
For compression fittings, thermowell or direct mounting
